Leviton 4710 | NEMA L5-15R 15A 125V Locking Receptacle | LeanLight

Leviton

4710 | NEMA L5-15R 15A 125V Locking Receptacle

$9.99 $12.49

Leviton 4710 is an industrial-grade 15A 125V locking receptacle built to provide unparalleled quality and superior performance in the most severe industrial settings. Leviton combines the best materials available with superior production standards to produce a high quality product that comes with a lifetime warranty. The female style outlet is 15 Amp,125 Volt, Single Locking Receptacle, Industrial Grade, Grounding, Black.  NEMA L5-15R, 2P, 3W

Electrical Specifications
  • Grounding: Grounding
  • Amperage: 15 Amp
  • Voltage: 125 Volt
  • Pole: 2
  • Wire: 3
  • Dielectric Voltage: Withstands 2000V per UL498
  • Current Limiting: Full Rated Current
  • Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Environmental Specifications
  • Flammability: Rated V-2 per UL94
  • Operating Temperature: -40C to 60C
Material Specifications
  • Face Material: Nylon
  • Body Material: Nylon
  • Line Contacts: Brass .031 Thick
  • Terminal Screws: Brass 10-32
  • Grounding Screw: Brass 8-32
  • Yoke: Zinc-Plated Steel
  • Strap Material: Nickel-Plated Brass
  • Color: Black
Mechanical Specifications
  • Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
  • Terminal Accom.: 18-10 AWG
  • Product ID: Ratings and NEMA I.D. permanently marked on device
  • Termination: Side
Product Features
  • NEMA: L5-15R
  • Color: Black
Standards and Certifications
  • NEMA: WD-6
  • ANSI: C-73
  • UL498: File E13399
  • UL Fed Spec WC-596: File E13399
  • CSA C22.2 No. 42: File LR-406
  • NOM: 057
  • Warranty: Lifetime Warranty



L5-15R install instructions

L5-15R wiring diagram

L5-15R dimensions sheet
