Keystone KTEB-126-1-TP 26W CFL Electronic Ballast 120V

Keystone KTEB-126-1-TP 26W CFL Electronic Ballast – 120V Rapid Start

The Keystone Technologies KTEB-126-1-TP is a 120V rapid-start electronic ballast for one 26W 4-pin compact fluorescent lamp (CFQ26W). Compact 3.45" case for CFL fixtures and downlights. For 26W 4-pin CFL lamps (CFQ26W).



Key Features

• Operates 1 × CFQ26W 4-pin CFL
• Also operates select T8, T5, and CFS28W lamps
• Rapid start for reliable CFL ignition
• 120V input
• Compact 3.45" case
• Sound Rated A and thermally protected
• End-of-lamp-life protection
• 3-year manufacturer warranty from Keystone Technologies



Specifications

• Model: KTEB-126-1-TP
• Brand: Keystone Technologies
• Lamp Type: 26W 4-pin CFL (G24q / G23q)
• Number of Lamps: 1
• Start Method: Rapid Start
• Input Voltage: 120V
• Ballast Type: Electronic CFL
• Power Factor: Normal
• Ballast Factor: 0.90 (CFQ26W)
• Input Watts: 24W (CFQ26W)
• Sound Rating: A
• Dimensions: 3.45" L × 1.81" W × 1.21" H
• Mounting Centers: 2.88"
• Min. Start Temperature: 0°F
• Max. Case Temperature: 167°F
• Certifications: UL Listed, FCC Part 18 Class B
• Warranty: 3 Years

Keystone KTEB-126-1-TP specifications sheet



Compatible Lamps

• 1 × CFQ26W/G24q or CFQ26W/G23q
• 1 × CFS28W/GR10q
• 1 × F32T8 / F25T8 / F17T8 / F15T8 / F13T8
• 1 × F19T5 / F18T5 / FC9T5



Compatible With / Replaces

• Other 120V 1-lamp 26W 4-pin CFL electronic ballasts
• For 26W 4-pin CFL lamps (CFQ26W)



Common Applications

• CFL downlights and compact fixtures
• Residential and light commercial replacements
• 1-lamp 26W CFL housings
• Failed electronic CFL ballast replacements



Why Buy from Keystone Technologies?

• Reliable 26W CFL rapid-start performance
• Compact case for common CFL housings
• Also covers select T8 and T5 lamps
• 3-year manufacturer warranty
